Wastewater Treatment System Designed for ADU's

WaterPlantir™ is a micro scale wastewater treatment system that is specifically designed for consumers so it is smaller, offers wireless monitoring, and is built for lite and easy maintenance. Anyone can set it up (where allowed), and because it is small and above ground it is immune to flood, can be moved as required, and the treatment process altered and improved via over-air updates. It uses 2% the space of a traditional septic system.

The Micro

A single unit 3ft tall x 2ft wide x 4ft long that can be installed inside or outside. This unit does not have a tank for your solid waste. The solid waste is about 1 kg every 4-5 days. It can be discharged into an existing septic tank with drain field (even one that might be smaller than code allows) or stored in a much smaller holding tank than a traditional septic system. Perfect for adding an ADU to an existing home.

Empty Weight: 310 lbs

Full Weight: 940 lbs

Size (LxWxH): 4'x2'x3'

Voltage: 110V

Avg. Power: 100W

Peak Power: 400W

Connection: 1 1/2" NPT

Capacity: 60-100 GPD

The Micro Plus

The Micro sits inside a 4ft cube designed to look like a planter box - with customizable side panels. This system treats the wastewater and discharges sludge into the remaining space inside the unit. The treated water can be discharged by using either a drain field, irrigation, a directly. It arrives pre-assembled, palletized, and ready for hook up. Ideal for off-grid applications, the unit can be drained and moved as required.

Empty Weight: 515 lbs

Full Weight: 3100 lbs

Size (LxWxH): 4'x4'x4'
